Test coverage

Test coverage is the practice of measuring whether existing tests fully cover your code. That means surfacing areas which aren't currently being tested, such as: conditions, logic branches, functions and variables.

Coverage tests examine the instrumented code against a set of industry-accepted best practices. They act as the last line of QA to improve the quality of your test suite.

Code instrumentation with the coverage addon

Storybook provides an official test coverage addon. Powered by Istanbul, which allows out-of-the-box code instrumentation for the most commonly used frameworks and builders in the JavaScript ecosystem.

Set up the coverage addon

Engineered to work alongside modern testing tools (e.g., Playwright), the coverage addon automatically instruments your code and generates code coverage data. For an optimal experience, we recommend using the test runner alongside the coverage addon to run your tests.

Run the following command to install the addon.

npm install @storybook/addon-coverage --save-dev

Update your Storybook configuration (in .storybook/main.js|ts) to include the coverage addon.

// Replace your-framework with the framework and builder you are using (e.g., react-webpack5, vue3-webpack5)
import type { StorybookConfig } from '@storybook/your-framework';

const config: StorybookConfig = {
  stories: [],
  addons: [
    // Other Storybook addons
    '@storybook/addon-coverage', //👈 Registers the addon
  ],
};

export default config;

Start your Storybook with:

npm run storybook

Finally, open a new terminal window and run the test-runner with:

npm run test-storybook -- --coverage

Configure

By default, the @storybook/addon-coverage offers zero-config support for Storybook and instruments your code via istanbul-lib-instrument for Webpack, or vite-plugin-istanbul for Vite. However, you can extend your Storybook configuration file (i.e., .storybook/main.js|ts) and provide additional options to the addon. Listed below are the available options divided by builder and examples of how to use them.

// For Vite support add the following import
// import type { AddonOptionsVite } from '@storybook/addon-coverage';

import type { AddonOptionsWebpack } from '@storybook/addon-coverage';

// Replace your-framework with the framework and builder you are using (e.g., react-webpack5, vue3-webpack5)
import type { StorybookConfig } from '@storybook/your-framework';

const coverageConfig: AddonOptionsWebpack = {
  istanbul: {
    include: ['**/stories/**'],
    exclude: ['**/exampleDirectory/**'],
  },
};

const config: StorybookConfig = {
  stories: [],
  addons: [
    // Other Storybook addons
    {
      name: '@storybook/addon-coverage',
      options: coverageConfig,
    },
  ],
};

export default config;

What about other coverage reporting tools?

Out of the box, code coverage tests work seamlessly with Storybook's test-runner and the @storybook/addon-coverage. However, that doesn't mean you can't use additional reporting tools (e.g., Codecov). For instance, if you're working with LCOV, you can use the generated output (in coverage/storybook/coverage-storybook.json) and create your own report with:

npx nyc report --reporter=lcov -t coverage/storybook --report-dir coverage/storybook

Troubleshooting

Run test coverage in other frameworks

If you intend on running coverage tests in frameworks with special files like Vue 3 or Svelte, you'll need to adjust your configuration and enable the required file extensions. For example, if you're using Vue, you'll need to add the following to your nyc configuration file (i.e., .nycrc.json or nyc.config.js):

export default {
  // Other configuration options
  extension: ['.js', '.cjs', '.mjs', '.ts', '.tsx', '.jsx', '.vue'],
};

The coverage addon doesn't support optimized builds

If you generated a production build optimized for performance with the --test flag, and you're using the coverage addon to run tests against your Storybook, you may run into a situation where the coverage addon doesn't instrument your code. This is due to how the flag works, as it removes addons that have an impact on performance (e.g., Docs, coverage addon). To resolve this issue, you'll need to adjust your Storybook configuration file (i.e., .storybook/main.js|ts) and include the disabledAddons option to allow the addon to run tests at the expense of a slower build.

// Replace your-framework with the framework you are using (e.g., react-webpack5, vue3-vite)
import type { StorybookConfig } from '@storybook/your-framework';

const config: StorybookConfig = {
  framework: '@storybook/your-framework',
  stories: ['../src/**/*.mdx', '../src/**/*.stories.@(js|jsx|mjs|ts|tsx)'],
  addons: [
    '@storybook/addon-essentials',
    '@storybook/addon-interactions',
    '@storybook/addon-coverage',
  ],
  build: {
    test: {
      disabledAddons: ['@storybook/addon-docs', '@storybook/addon-essentials/docs'],
    },
  },
};

export default config;

The coverage addon doesn't support instrumented code

As the coverage addon is based on Webpack5 loaders and Vite plugins for code instrumentation, frameworks that don't rely upon these libraries (e.g., Angular configured with Webpack), will require additional configuration to enable code instrumentation. In that case, you can refer to the following repository for more information.
